Condensate pot is utilized in steam pipelines to
achieve accurate flow measurement, which provides
an interface between the vapor and the liquid.
Technical Data 1
- Chambers of seamless structure without welded caps
- Provides safety according to 'Hot spinning forming' in the manufacturing process
- Volume from 200cc to 3785cc (1gal) with availability of customized size
Technical Data 2
- Working pressure up to 10150psi (700bar)
- Working Temperature: -58 ℉ ~ 932 ℉ (-50 ℃ ~ 500 ℃)
- End-connections with 1/4", 1/2" Female NPT and Socket welding
Technical Data 3
- Various shapes (2 Pot ~ 4 Pot), Materials, Pipe size (2" ~ 6"), Thickness (SCH40 ~ SCH160) available
- Options including Vent plug, Hex head plug, Valves and Flexible Metal Hose
- Materials with 316L, 304L, Duplex, Super Duplex, Alloy 625/825, 6MO, Monel, Hastelloy
Technical Data 4
- MTC 3.1 Certificate with ONLY G7 and South Korean raw material
- Seamless Pipe with NACE MR 0175/0103
